M-Screen 8503 Openness Factor: ±3% UV Blockage: ±97% Standard Roll Widths: 78”, 98” Composition: 36% Fiberglass / 64% Vinyl Mesh/Inch: 56 Warp / 56 Fill Mesh Weight: 12.70 oz./yd2 Fabric Thickness (inch): 0.022 Breaking Strength (lbs): 290 Warp / 280 Fill Environmental Certification: GREENGUARD Indoor Air Quality
Certified for low emissions (LEED™) GREENGUARD for Children and Schools
Certified Fire Classification: California U.S. Tile 19, NFPA 701-99 TM
#1, M1 NFP 92 503 Bacteria & Fungai Resistance: ASTM E 2180, ASTM G21 SolarOptical Properties: Fenestration data is available upon
request Railroading: No | M-Screen 8505 Openness Factor: ±5% UV Blockage: ±95% Standard Roll Widths: 78”, 98” Composition: 36% Fiberglass / 64% Vinyl Mesh/Inch: 56 Warp / 56 Fill Mesh Weight: 12.10 oz./yd2 Fabric Thickness (inch): 0.022 Breaking Strength (lbs): 290 Warp / 280 Fill Environmental Certification: GREENGUARD Indoor Air Quality
Certified for low emissions (LEED™) GREENGUARD for Children and Schools
Certified Fire Classification: California U.S. Tile 19, NFPA 701-99 TM
#1, M1 NFP 92 503, ASTME84 Bacteria & Fungai Resistance: ASTM E 2180, ASTM G21 SolarOptical Properties: Fenestration data is available upon
request Railroading: No |
