SheerWeave 4600
Openness Factor: ±3%
UV Blockage: ±97%
Standard Roll Widths: 63”, 98”
Composition: 22% Polyester / 78% Vinyl
Mesh/Inch: 45 Warp / 35 Fill
Mesh Weight: 17.40 oz./yd2Yarn Diameter (inch): 0.013 Warp / 0.020 Fill
Fabric Thickness (inch): 0.030 Breaking Strength (lbs): 183 Warp / 308 Fill Stiffness (Mg): 230 Warp / 439 Fill Fire Classification: California U.S. Title 19 (small scale), NFPA 701 TM #1 (small scale), British Standard 5867 Type B,
ASTM E 84 (Class I) Bacteria & Fungal Resistance: ASTM-G21, ASTM-G22 Environmental Certification: GREENGUARD Certified (Indoor Air Quality) and GREENGUARD for Children and Schools Certified, RoHS Compliant Solar Optical Properties: Fenestration data is available upon request Railroading: Yes | SheerWeave 4500
Openness Factor: ±5%
UV Blockage: ±95%
Standard
Roll Widths: 63”, 98”
Composition: 17% Polyester / 83% Vinyl
Mesh/Inch: 45 Warp / 42 Fill
Mesh Weight: 14.40 oz./yd2Yarn Diameter (inch): 0.013 Warp / 0.013 Fill Fabric Thickness (inch): 0.024 Breaking Strength (lbs): 181 Warp / 168 Fill Stiffness (Mg): 240 Warp / 190 Fill Fire Classification: California U.S. Title 19 (small scale), NFPA 701 TM #1 (small scale), British Standard 5867 Type B,
ASTM E 84 (Class I) Bacteria & Fungal Resistance: ASTM-G21, ASTM-G22 Environmental Certification: GREENGUARD Certified (Indoor Air Quality) and GREENGUARD for Children and Schools Certified, RoHS Compliant Solar Optical Properties: Fenestration data is available upon request Railroading: Yes |
